SBE-26CB Formula D
SBE, Opti-Scan; California City (CA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- SBE, Opti-Scan; California City (CA)
- Year
- 1977 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 337212
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: SBE-26CB Formula D - SBE, Opti-Scan; California
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 170 x 60 x 235 mm / 6.7 x 2.4 x 9.3 inch
- Notes
-
CB Transceiver 69 channels, only AM, divided into three bands: Low Medium High, 23 channels per band. Power output 5 Watt. Squelch, noise limiter and PA. Remote/local switch.
First price n Italy (1977) 225,000 ITL.
- Mentioned in
- -- Original prospect or advert ("CQ Elettronica", Italy, CD editor, number 124, April 1977.)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
