• Country
• Germany

• Manufacturer / Brand
• Schaub und Schaub-Lorenz

• Year
• 1963/1964

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 24988

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EBF89 ECC83 EM84 ELL80

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-117; 127; 220; 240-250 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Ballerina Stereo 40 22550 [poliert] - Schaub und Schaub-Lorenz

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 990 x 760 x 370 mm / 39 x 29.9 x 14.6 inch

• Notes

• Rundfunk-Chassis = 93254, Stereo-NF-Verstärker mit 2 Endstufen je 3,5 W,
  nachrüstbarer Stereo-Decoder;
  Phono-Chassis = Perpetuum-Ebner PE66.

• Net weight (2.2 lb = 1 kg)
• 32.6 kg / 71 lb 12.9 oz (71.806 lb)

• Price in first year of sale
• 798.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1963/1964

• Literature/Schematics (1)
• -- Original-techn. papers.

• Other Models

• Here you find 972 models, 830 with images and 690 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
