• Country
• Germany

• Manufacturer / Brand
• Schaub und Schaub-Lorenz

• Year
• 1963/1964

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 108557

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• A59-12W

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Illustra 4059 80640/80641 - Schaub und Schaub-Lorenz

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 820 x 920 x 440 mm / 32.3 x 36.2 x 17.3 inch

• Notes
• VHF/UHF. Technische Daten wie Weltecho 4059, jedoch Truhe mit verschließbaren Türen.

• Net weight (2.2 lb = 1 kg)
• 42.8 kg / 94 lb 4.4 oz (94.273 lb)

• Price in first year of sale
• 1,168.00 DM

• Source of data
• Handbuch VDRG 1963/1964

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
