Illustraphon 17S 8584
Schaub und Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- Schaub und Schaub-Lorenz
- Year
- 1954–1956
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 229048
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- PCC84 PCC85 EF94 EF94 EF94 EF80 PL83 EF94 EF94 EF93 PL82 ECC81 ECC81 PL82 ECC81 PL81 PY83 EY51 Bs42R-3
- Main principle
- Superhet with RF-stage; ZF/IF 25700 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Radio Control (+Remote Wire etc)
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Illustraphon 17S 8584 - Schaub und Schaub-Lorenz
- Shape
- Console with any shape - in general
- Notes
-
Schaub-Lorenz, Illustraphon 17S Type 8584
Kanalwähler für 10 Kanäle im VHF-Band I und III + 2 Reserve-Kanäle.
Die kabelgebundene Fernbedienung Typ 0015 enthält die Bedienelemente zum Einstellen der Lautstärke und des Bildkontrasts.
