Illustraphon 3559 Luxus 70452/70453/70454/70455
Schaub und Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- Schaub und Schaub-Lorenz
- Year
- 1962
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 180617
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- PCC88 PCF82 PC88 PC86 PCF82 EF183 EF80 EF80 EF80 EF80 PCL84 PCL84 EAA91 ECH84 ECH84 PCL85 EBC91 PL500 PY88 DY86 A59-12W
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Illustraphon 3559 Luxus 70452/70453/70454/70455 - Schaub und Schaub-Lorenz
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 934 x 912 x 420 mm / 36.8 x 35.9 x 16.5 inch
- Notes
- Der Fernsehempfänger Illustraphon 3559 Luxus ist für den Empfang von VHF und UHF ausgelegt. Die Auslieferung erfolgte mit oder ohne UHF- Tuner.
- Net weight (2.2 lb = 1 kg)
- 50.5 kg / 111 lb 3.7 oz (111.233 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
