Kongress Goldserie UKW

Schaub und Schaub-Lorenz

Data
Forum
Pictures
Collections

  • Year
  • 1956/1957
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 112326

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); 2 AF stage(s)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Kongress Goldserie UKW - Schaub und Schaub-Lorenz
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 360 x 235 x 190 mm / 14.2 x 9.3 x 7.5 inch
  • Notes

  • It has Maritime short wave and Dial Scale in Portuguese language.

    See also the similar model Kongress UKW 3056 with different front shape.

  • Price in first year of sale
  • 2,280.00 PTE
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Mario Coelho. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Kongress Goldserie is part of the collections of the following members.
