• Country
• Germany

• Manufacturer / Brand
• Schaub und Schaub-Lorenz

• Year
• 1961–1963

• Category
• Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter

• Radiomuseum.org ID
• 107614

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• EC88 EC86

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: UHF-Konverter FK20 - Schaub und Schaub-Lorenz

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 215 x 70 x 172 mm / 8.5 x 2.8 x 6.8 inch

• Notes

• UHF Kanäle 14-53, Umsetzung auf VHF Kanal 3 oder 4. Eingebautes Thermo-Relais zum automatischen Ein-/Ausschalten. Gehäuse wahlweise in sandgrau oder weinrot.

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Price in first year of sale
• 160.00 DM

• Source of data
• Handbuch VDRG 1962/1963
