Visophon 8184
Schaub und Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- Schaub und Schaub-Lorenz
- Year
- 1954/1955
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 19922
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- PCC84 PCC85 EF94 EF94 EF94 EF80 PL83 EF94 EF94 EF93 PL82 ECC81 ECC81 PL82 ECC81 PL81 PY83 EY51 Bs42R-3
- Number of Transistors
- Main principle
- Superhet with RF-stage; ZF/IF 25700 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Visophon 8184 - Schaub und Schaub-Lorenz
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 560 x 910 x 470 mm / 22 x 35.8 x 18.5 inch
- Notes
-
Schaub-Lorenz, Visophon Type 8184
Kanalwähler für 10 Kanäle im VHF-Band I und III + 2 Reserve-Kanäle.
Die kabelgebundene Fernbedienung Typ 0015 enthält die Bedienelemente zum Einstellen der Lautstärke und des Bildkontrasts.
- Net weight (2.2 lb = 1 kg)
- 40 kg / 88 lb 1.7 oz (88.106 lb)
- Price in first year of sale
- 1,048.00 DM
- External source of data
- Erb
- Source of data
- Rundfunk- und Fernseh-Katalog 1954/55
- Mentioned in
- Rundfunk-Phono-Fernseh-Katalog 1954-1955 2.Aufl. S.132 (Thiele)
