Weltecho 2059 73347
Schaub und Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- Schaub und Schaub-Lorenz
- Year
- 1961/1962
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 105583
Ebay DE Auktion 260511150499
Ebay DE Auktion 260511150499
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- AW59-90
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Details
- Radio Control (+Remote Wire etc)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Weltecho 2059 73347 - Schaub und Schaub-Lorenz
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 590 x 485 x 360 mm / 23.2 x 19.1 x 14.2 inch
- Notes
- Schaub-Lorenz Weltecho 2059, Typ: 73347;
59 cm s/w TV mit CCIR B/G VHF & UHF Tuner,
190 W Leistungsaufnahme.
- Net weight (2.2 lb = 1 kg)
- 34 kg / 74 lb 14.2 oz (74.89 lb)
- Price in first year of sale
- 975.00 DM
- Source of data
- HdB d.Rdf-& Ferns-GrH 1961/62
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
