• Country
• Germany

• Manufacturer / Brand
• Schneider Rundfunkwerke, Electronics (Schneider/TCL); Türkheim

• Year
• 1976 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 117018

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 31

• Semiconductors
• BF324 BF451 BF240 BF241 BF245 BF440 BC238 BC239 BC307 BC174 BD377 BD378 BD607 2N6099 AA112 ZF18 ZY24 ZE4,7 BA181 1N4002 BB104 BB113 SAS580 SAS590 CA3089 CA3090 TBA625 TBA271

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (90 W max.)

• from Radiomuseum.org
• Model: Stereo-Kompaktanlage Multisound 1090 CP Ch= 4000 [ab Nr. 1000] - Schneider Rundfunkwerke,

• Shape
• Chassis only or for «building in»

• Notes
• Halbleiter teilweise mehrfach vorhanden.
  UKW-Tuner: Fertigbaustein FD1A von Valvo.
  Ausgangsleistung: 2× 40 W.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
