- Country
- Germany
- Manufacturer / Brand
- Schneider Rundfunkwerke, Electronics (Schneider/TCL); Türkheim
- Year
- 1986/1987
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 174121
Prospekt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Record Player + Tape Recorder; Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 80 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Midi 2600RC - Schneider Rundfunkwerke,
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 350 x 425 x 340 mm / 13.8 x 16.7 x 13.4 inch
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Jaroslav Hlavaty. See "Data change" for further contributors.
