Frequenzwahlstufe M947
Schomandl KG; München
- Country
- Germany
- Manufacturer / Brand
- Schomandl KG; München
- Year
- 1966
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 228503
-
- Brand: Meto
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage and/or dry batteries / 12 DC Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Frequenzwahlstufe M947 - Schomandl KG; München
- Shape
- Miscellaneous shapes - described under notes.
- Notes
-
Die Frquenzwahlstufe M947 findet Anwendung in dekadisch einstellbaren Frequenzsynthesatoren(Frquenzdekaden).
Die Geräte setzen eine Quarzfrequenz in eine wählbare Ausgangsfrequenz um.
- Net weight (2.2 lb = 1 kg)
- 0.670 kg / 1 lb 7.6 oz (1.476 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Rudolf Müller. See "Data change" for further contributors.
