Sprechfunkmeßplatz FD450
Schomandl KG; München
- Country
- Germany
- Manufacturer / Brand
- Schomandl KG; München
- Year
- 1978 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 127477
-
- Brand: Meto
Sammlung
Funkschau 4.1977
Sammlung
Sammlung
Sammlung
Sammlung
Sammlung
Sammlung
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Line / Batteries (any type) / 220; 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: Sprechfunkmeßplatz FD450 - Schomandl KG; München
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 490 x 280 x 210 mm / 19.3 x 11 x 8.3 inch
- Notes
- Frequenzbereich 26 bis 471MHz, Betrieb als Meßsender und Empfänger. Selective Leistungsmessung, Eingangsempfindlichkeit typ. 500µV, Spitzenhub und Mittenträgeranzeige.
- Net weight (2.2 lb = 1 kg)
- 21.6 kg / 47 lb 9.2 oz (47.577 lb)
- Mentioned in
- Funkschau (4.1977)
- Author
- Model page created by Karlheinz Fischer. See "Data change" for further contributors.
