Erec-Tronic Set T-200

Science Electronics Inc.; Cambridge, MA

Data
Forum
Pictures
Collections

  • Year
  • 1955 ?
  • Category
  • Kit (Parts plus instruction) or building instructions only
  • Radiomuseum.org ID
  • 356330
    • Brand: ErecTronic

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • 1T4
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Dry Batteries / D: 1 x 1.5 & 45 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Special material, described in the notes.
  • from Radiomuseum.org
  • Model: Erec-Tronic Set T-200 - Science Electronics Inc.;
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 9 x 12 x 0.25 inch / 229 x 305 x 6 mm
  • Notes

  • This is an educational prototyping kit. The baseboard is a fiber press board 0.25 inch thick with a grid of 0.25 inch holes on 0.5 inch centers. Components are mounted on plastic carriers that have pegs on the bottom of them to match the perforated base. There are templates, which are also the schematics for all the circuits that can be built with this kit.

  • Net weight (2.2 lb = 1 kg)
  • 3 lb (3 lb 0 oz) / 1.362 kg
  • Price in first year of sale
  • 15.00 USD
  • Mentioned in
  • -- Original prospect or advert (Popular Electronics Magazine Feb 1955, pp 56 (T-100))
  • Literature/Schematics (1)
  • -- Schematic
  Erec-Tronic model T-200 manual 2373 KB
