Dual Channel Oscilloscope 4D-10

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Scopex Instruments; Letchworth, Hertfordshire

• Year
• 1976 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 187050

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• D10-160GH

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 210; 230; 250 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Dual Channel Oscilloscope 4D-10 - Scopex Instruments; Letchworth

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 12.25 x 6 x 14.25 inch / 311 x 152 x 362 mm

• Notes
• Screen size: 8 x 6 cm.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 1,100.00 DM

• Mentioned in
• Funk-Technik (FT) (22/76 Seite 737.)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Egon Strampe. See "Data change" for further contributors.

• Other Models

• Here you find 8 models, 7 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Scopex Instruments; Letchworth, Hertfordshire
