• Country
• United States of America (USA)

• Manufacturer / Brand
• Scott; H.H.; Maynard, Massachusetts

• Year
• 1961/1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 159180

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6BS8 6U8 6AU6 6AU6 6BN6 6BL8 12AU7 12AU7 12AT7 6X4

• Main principle
• Superheterodyne (common)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Wideband 350 - Scott; H.H.; Maynard,

• Shape
• Book-shelf unit.

• Notes
• FM Multiplex Stereo Tuner.

• Price in first year of sale
• 195.00 $

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.

• Other Models

• Here you find 181 models, 164 with images and 74 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
