• Country
• United States of America (USA)

• Manufacturer / Brand
• Scott Radio Labs.(E.H., Transformer); Chicago (IL)

• Year
• 1944

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 118904

• Number of Tubes
• 12

• Valves / Tubes
• 6K7 12J5 12SA7 12SK7 1629 12SK7 12H6 12SN7GT 12SN7GT 25L6GT 25L6GT 25Z6GT

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• AC/DC-set / 115 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: SLR-M - Scott Radio Labs.E.H.,

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Notes

• Low radiation receiver.

  Variations: REE, SLR-M, Export Receiver.

• Source of data
• E.H.Scott Radio Collectors Guide (1925-1946)

• Literature/Schematics (1)
• Rider's Perpetual, Volume 18 = covering late 1947 to early 1948 (see Export Receiver)

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
