• Country
• United States of America (USA)

• Manufacturer / Brand
• Scott Radio Labs.(E.H., Transformer); Chicago (IL)

• Year
• 1931

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 55379

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC)

• Material
• Metal case, TUBES VISIBLE

• from Radiomuseum.org
• Model: All Wave 12 two dial Chrome CHASSIS [production] - Scott Radio Labs.E.H.,

• Shape
• Chassis only or for «building in»

• Notes
• Plug in coils for wave change 15 - 550 meter.

• Price in first year of sale
• 212.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932
