Silvertone Order= 57EM 1732
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 55933
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone Order= 57EM 1732 - Sears, Roebuck & Co.; Chicago
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 25 x 41 x 14 inch / 635 x 1041 x 356 mm
- Notes
- 2 Speakers : 8 and 12 inch.
- Price in first year of sale
- 84.50 $
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 4 = ca. 1934 and before
- Mentioned in
- Pre-War Consoles
- Literature/Schematics (1)
- Riders 4-26, 27, 28
- Literature/Schematics (2)
- The Sears Silvertone Catalogs 1930-1942 (page 75)
- Literature/Schematics (3)
- Sears, Roebuck Catalogs (Silvertone) (# 168, Spring & Summer 1934, page 371.)
