Silvertone 1835 Order= 57HM 1835

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1935
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 55983
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 9
  • Main principle
  • Superheterodyne (common); ZF/IF 445 kHz; 2 AF stage(s)
  • Tuned circuits
  • 9 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / Either 25 cycles, 110V or 50 to 60 cycles, 110 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 1835 Order= 57HM 1835 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 24 x 37 x 12 inch / 610 x 940 x 305 mm
  • Notes

  • The Sears Silvertone 1835 is an AC operated 9 tube BC and SW band receiver.  Has AVC, 2 IF stages and push-pull output stage.  Riders has IF at 456kHz while Sears Silvertone Service Manual 1928 thru 1936 has IF at 445kHz (These are close so it should not make much difference which one is actually used for alignment).

    Band Frequency Ranges are as follows:
    BC Band.............545-1713kHz
    SW Band............5.8-17.9MHz

    Catalog States: Equipped with dual control which makes possible the positive tuning of hard-to-get foreign stations.  One control, like the hour hand of a watch, is tuned to the general position of the station you want, and the minute hand control is then used to exactly locate the station.

    The Cabinet is of choice wood veneers with instrument panel of matched walnut.  Side front panels of striped walnut veneers, remainder walnut finished.  Aerial kit included.

    Order number 57HM 1835 Cash Price $ 48.95.  See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).

  • Price in first year of sale
  • 48.95 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 7 = 1936 and before
