Silvertone 1998 Late

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1936
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 56117
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 262 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / Either Transformer: 25 cycles, 110 to 125V or 60 cycles, 110 to 125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 1998 [Late] - Sears, Roebuck & Co.; Chicago
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 21 x 37 x 12 inch / 533 x 940 x 305 mm
  • Notes

  • The Sears Silvertone 1998 is an AC operated 7 tube BC and SW band receiver. Has push-pull output stage. An optional wavetrap was available for receivers located near airports using transmitters operating at or near the 262kHz IF frequency.  Early versions of this model did not have circuit changes to reduce hum when tone control was in bass position.

    See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 7 = 1936 and before
