• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1935

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 56233

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 1C6 1A4 951 1F4

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 90 & 67.5 & 2 or 3 Volt

• Loudspeaker
• Magnetic loudspeaker (reed) generic. / Ø 6 inch = 15.2 cm

• Power out
• 0.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Silvertone 4408 Ch= 101.414 - Sears, Roebuck & Co.; Chicago

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes
• A Batery = 3V Dry or 2V Storage battery.

• External source of data
• Ernst Erb

• Source of data
• Guide to Old Radios

• Circuit diagram reference
• Rider's Perpetual, Volume 7 = 1936 and before

• Literature/Schematics (1)
• Riders 7-49, 50
