Silvertone 4528
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1936 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 220236
-
- Brand: Silvertone
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 4528 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel, low profile (big size).
- Notes
- The Sears Silvertone model 4528 is a battery operated BC/LW/SW farm radio. Operates from a 6V storage battery. Uses a vibrator to generate the B+ voltage.
- Mentioned in
- Machine Age to Jet Age II (page 263.)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
