Silvertone Order= 57KM 6064 Ch= 101.505

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1937–1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 56616
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 465 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Storage and/or dry batteries / 4,5 (storage b.) & batt. 2 x 45 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
  • Power out
  • 0.8 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone Order= 57KM 6064 Ch= 101.505 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 22 x 37 x 13.25 inch / 559 x 940 x 337 mm
  • Notes
  • The Silvertone model 6064 is the same as model 6065 except using a 4,5 volts dry "A" battery. It is without "Flash O Lite".

    The Silvertone 6064 is a model taken from Rider's Page 10-7 with a date April 15 from 1938. Then it has probably been produced already in 1937 - together with the following models on that plan: 4632A, 4633A, 6014, 6015, 6044, 6045, 6064, 6144, 6164, Chassis 101.505 or 101.505X. They use a storage battery for the tube heaters and two 45 volt batteries.
  • Price in first year of sale
  • 33.95 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 10 = 1939 and before
