Silvertone Order= 57DM 6352 Ch= 101.580

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1939/1940
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 56814
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage and/or dry batteries / 90 & 2 or 1.4 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Power out
  • 0.17 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone Order= 57DM 6352 Ch= 101.580 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 16 x 10 x 10 inch / 406 x 254 x 254 mm
  • Notes

  • This model includes one storage "A" battery and two "B" batteries, see also model 6350 and model 6351.

  • Price in first year of sale
  • 19.99 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 11 = ca. 1940 and before
  • Literature/Schematics (1)
  • Riders 11-77
