Silvertone 7210 Ch= 101.820
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 57096
-
- Brand: Silvertone
Beitman
SAMS
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (not changer)
- Power type and voltage
- Dry Batteries / comb. Batt. 1.5 & 90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 7210 Ch= 101.820 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Notes
- The Battery operated combination phono-radio model Silvertone 7210 from Sears, Roebuck & Co. with chassis 101.820 has an 4" x 6" elliptical speaker. It is also called Farm Radio / Crank Phono.
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 17 = 1948 and before
- Mentioned in
- Collector's Guide to Antique Radios (6th edition)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 1-48, set 32, folder 482-20 und Beitman 1948)
