Silvertone 1019 Order=57H 1019
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1960/1961
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 251078
-
- Brand: Silvertone
- Number of Transistors
- 7
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / Either AC: 25 to 60 cycles, 110 to 120V or DC: 110 to 120V or 6 x 1.5 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Silvertone 1019 Order=57H 1019 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 13 x 8 x 4 inch / 330 x 203 x 102 mm
- Notes
-
The Sears Silvertone 1019 is a AC/DC/Battery operated 7 transistor portable AM band radio. Cabinet color is Brown and Ivory. Has Qty(1) PM 3" speaker and Qty(1) PM 5" speaker. Operates from line voltage or Qty(6) 1.5V "D" batteries. Has handle and white metal grille. Also has phonograph input.
- Price in first year of sale
- 39.95 $
- Literature/Schematics (2)
- Sears, Roebuck Catalogs (Silvertone) (Winter 1961, page 93.)
- Literature/Schematics (3)
- Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1960, page 1309.)
- Author
- Model page created by Noemi Erb. See "Data change" for further contributors.
