• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1930/1931

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 92962

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UX201A UX201A UX201A UX201A UX112A

• Main principle
• TRF without regeneration; Neutrodyne

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 2 x 4.5 volt "C" batteries & storage battery 6.3 volt & "B" 3 x 45 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Silvertone 5-Tube Neutrodyne Order= 57DM 1050 or 1052 - Sears, Roebuck & Co.; Chicago

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 15.2 x 7.5 x 8.25 inch / 386 x 191 x 210 mm

• Notes
• The Sears Silvertone 5-Tube neutrodyne has a single dial tuning and volume control on front.
  Order number 57DM 1050 1/4 without speaker, tubes or accessories for $ 21.50 or 57DM 1052 1/4 with all tubes, batteries, aerial and 57D4832 loudspeaker for 47.50 or as 57DM 1053 1/4 for easy payment: $ 8 "down" cash and $ 5 per month until paid $ 52.25. See details and summaries about Sears catalogs etc.

• Price in first year of sale
• 21.50 $ +

• Mentioned in
• Sears, Roebuck Catalogs (Silvertone) (#161, Fall & Winter 1930/31, page 902.)

• Literature/Schematics (1)
• The Sears Silvertone Catalogs 1930-1942 (page 20)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
