Silvertone 109A Order= 57DM 1090 or 1092

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1930/1931
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 203688
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • TRF without regeneration; Screengrid 1926-1935
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 110 Volt
  • Loudspeaker
  • -Loudspeaker incorporated, but system not known.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 109A Order= 57DM 1090 or 1092 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 25 x 39.5 x 15.75 inch / 635 x 1003 x 400 mm
  • Notes
  • The Sears Silvertone 109A 7-Tube All-Electric Screen Grid low-boy with a 5-ply veneer construction in lustrous, rich walnut has an "improved super-dynamic speaker". Two antenna posts for short or long antenna, phonograph pick-up, Push-Pull-output. The front panels are of genuine butt walnut veneer. Sliding casters protect polished floors.
    Order number 57DM 1090 1/4 without tubes or accessories for $ 67 (57DM 1091 1/4 for easy payment) or 57DM 1092 1/4 with all tubes and aerial for 79.50 or as 57DM 1093 1/4 for easy payment: $ 10 "down" cash and $ 9 per month until paid $ 87.50. See details and summaries about Sears catalogs etc.
  • Price in first year of sale
  • 67.00 $ +
