Silvertone 1949 5-Tube Auto Radio Second Version

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1936
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 224501
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Silvertone 1949 5-Tube Auto Radio [Second Version] - Sears, Roebuck & Co.; Chicago
  • Shape
  • Chassis only or for «building in»
  • Notes

  • The Sears Silvertone 1949 is a 6V battery operated 5 tube BC band car radio.  Uses Vibrator to generate the B+ voltage.  Has Bias cell. Chassis and schematic used in this model also used in model 7167.

    See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Corona Radio and Television Corp., Chicago, Ill (Sears Manufacturer Source Number Code 104).

    There is also a different Sears Silvertone 1949 car radio model from the same year, from the same manufacturer and has the same tube line-up!! The schematic of this model is slightly different.

  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
