Silvertone 1986 Ch= 101.407F
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 223931
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 262 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 25 cycles, 105-125V and 50-60 cycles, 105-125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Power out
- 2.66 W (4 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 1986 Ch= 101.407F - Sears, Roebuck & Co.; Chicago
- Notes
-
The Silvertone 1986 is an AC operated 6 tube BC/Police and SW band receiver.
Band Frequency Ranges are as follows:
BC Band (Band A).............545-1750kHz
Police Band (Band P)........2.2-6.5MHz
SW Band (Band F)............6.2-18.0MHzSee details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).
- Literature/Schematics (1)
- Rider's Perpetual, Volume 7 = 1936 and before (Riders 7-45, 46)
- Literature/Schematics (2)
- Silvertone Radios, Service Inf. 1928 thru 1936 (Pages 894 to 901)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
