Silvertone 3014 Order=57H 3014
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1962/1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 251707
-
- Brand: Silvertone
- Number of Tubes
- 7
- Valves / Tubes
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- AC/DC-set / Either AC: 25 - 60 cycles, 105 - 120V or DC: 105 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Silvertone 3014 Order=57H 3014 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 13 x 7 x 5 inch / 330 x 178 x 127 mm
- Notes
-
The Sears Silvertone 3014 is an AC/DC operated 7 Tube AM/FM Receiver. Has ferrite rod antenna for AM and uses line cord for FM antenna. Cabinet color is charcoal gray and ivory with silver-color trim.
The following models use the same schematic and chassis:
Model Cabinet Color 3014 Charcoal gray and ivory 3015 Ivory 3016 Blue mist and ivory See details and summaries about Sears catalogs etc.
- Price in first year of sale
- 28.95 $
- Literature/Schematics (2)
- Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1962, page 1246.)
- Literature/Schematics (3)
- Sears, Roebuck Catalogs (Silvertone) (Spring/Summer 1963, page 1275.)
- Author
- Model page created by Noemi Erb. See "Data change" for further contributors.
