Silvertone 3042 Ch= 528.54411 Order=57H 3042

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1962/1963
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 251698
    • Brand: Silvertone

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Silvertone 3042 Ch= 528.54411 Order=57H 3042 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 14 x 7 x 4 inch / 356 x 178 x 102 mm
  • Notes

  • The Sears Silvertone 3042 is an AC operated 6 tube AM Radio with electric clock. The AM band tuning range is 540 to 1645kHz. Has 1100W utility outlet on rear of chassis which is controlled by the clock.  Cabinet color is ivory with silver color trim.

    The following models use the same schematic:

    Model Chassis Cabinet Color
    3041 528.54411 Charcoal gray
    3042 528.54411 Ivory
    4043 528.54670 ??
    4040 528.54670 ??

    See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Warwick Electronics, Chicago, Ill. (Sears Manufacturer Source Number Code 528).

  • Price in first year of sale
  • 33.95 $
  • Author
  • Model page created by Noemi Erb. See "Data change" for further contributors.
