Silvertone 41 Ch= 528.53610 Order=57K 41

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1959/1960 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 144431
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Silvertone 41 Ch= 528.53610 Order=57K 41 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 14 x 6 x 5 inch / 356 x 152 x 127 mm
  • Notes

  • The Sears Silvertone 41 is an AC operated 6 tube AM receiver with electric clock. AM band tuning range is 532 to 1620kHz. Has 1100W appliance outlet which is controlled by the clock.

    The following models use the same schematic and chassis:

    Model Cabinet Color
    39 Brown
    40 Ivory
    41 Ice Blue

    See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Warwick Electronics, Chicago Ill. (Sears Manufacturer Source Number Code 528).

    Sams photofact set 473 folder 15 date 2-60 features the Silvertone models 39, 40, 41 with chassis 528.53610, the models 42, 43, 44, 45 with chassis 528.53700 and the models 9027, 9028, 9029 with chassis 528.53730 as the same schematic.

    There is a conflict regarding the speaker size, with SAMS listing a 4" speaker while the Sears catalog lists a 5" speaker.

  • Price in first year of sale
  • 34.95 $
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
