• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1957 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 312182

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Silvertone Ch= 567.41109 - Sears, Roebuck & Co.; Chicago

• Shape
• Chassis only or for «building in»

• Notes

• The Silvertone chassis 567.41109 four record changer is designed to play 78 RPM, 45 RPM, 33 1/3 RPM and 16 RPM records of standard commercial dimensions.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 365 Folder 13 dated 7-57)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
