Silvertone 6074 Ch= 567.34004
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1957 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 317504
-
- Brand: Silvertone
Picture from service manual.
front view
top view
chassis
underside
inside of the cabinet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 6074 Ch= 567.34004 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Silvertone model 6074 tape recorder is designed to record and playback two tracks of material on standard widt recording tape.This doubles the recording and playing time with no loss of frequency response or quality.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 379 Folder 12 dated 11-57)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
