• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1956/1957

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 270633

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6BJ6 12BE6 6BJ6 12AT6 50C5 35W4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Silvertone 7025 Ch= 528.46700 - Sears, Roebuck & Co.; Chicago

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Dimensions (WHD)
• 14.25 x 5.75 x 6.25 inch / 362 x 146 x 159 mm

• Notes

• The Sears Silvertone 7025 is an AC operated 6 tube BC band clock radio with calender feature.  Has built in loop antenna and utility outlet on rear of chassis that is controlled by the clock.

  The following models use the same schematic and similar chassis:

  Model	Chassis	R12	Cabinet Color	Sears Catalog price
  7025	528.46700	15 ohms	Brown	$37.95
  7025	528.46701	27 ohms	Brown	$37.95
  7026	528.46700	15 ohms	Ivory	$39.95
  7026	528.46701	27 ohms	Ivory	$39.95
  7027	528.46700	15 ohms	Frosty Pink	$39.95
  7027	528.46701	27 ohms	Frosty Pink	$39.95

  See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Warwick Electronics, Chicago Ill. (Sears Manufacturer Source Number Code 528).

• Mentioned in
• Photofact Folder, Howard W. SAMS (Set 355, Folder 10 Date 4-57)

• Literature/Schematics (1)
• Beitman Radio Diagrams, Vol. 17, 1957 (Page 146)

• Literature/Schematics (2)
• Sears, Roebuck Catalogs (Silvertone) (Page 867)

• Literature/Schematics (3)
• Machine Age to Jet Age II (Page 270)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
