Silvertone 7030 Ch= 114
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1931/1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 222791
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 7030 Ch= 114 - Sears, Roebuck & Co.; Chicago
- Dimensions (WHD)
- 0 x 44 x 0 inch / 0 x 1118 x 0 mm
- Notes
-
This Silvertone 7030 is the 9-tube Super Heterodyne with chassis 114. It has a visual tuning meter and shares the same schematic/chassis as Silvertone 1430 with 9 tubes.
See details and summaries about Sears catalogs etc.
- Mentioned in
- Silvertone Radios, Service Inf. 1928 thru 1936 (page 220.)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
