Silvertone 7061

Sears, Roebuck & Co.; Chicago (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1934
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 227855
    • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 175 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / AC 60 cycles, 110V or DC 110 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Silvertone 7061 - Sears, Roebuck & Co.; Chicago
  • Shape
  • Tablemodel, with any shape - general.
  • Notes

  • The Sears Silvertone 7061 is an AC/DC operated 5 tube BC band receiver.  Has 154 ohm resistor built into the line cord (curtain burner).  Has AC/DC switch on rear of chassis which allows the field coil of the speaker to bypass the regulator tube when operating from a DC source.

    The chassis and schematic used in this model is also used in models 1700 and 7062. Riders Sears 4-1, 1 schematic is for model 1700 but Sears Silvertone Service Manual 1928 thru 1936 confirms that models 1700 and 7061 use the same schematic, thus Riders schematic is valid for this model.

    See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Colonial Radio Corp., Buffalo, NY (Sears Manufacturer Source Number Code 101).

  • Circuit diagram reference
  • Rider's Perpetual, Volume 4 = ca. 1934 and before
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
