• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1956 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 283867

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycle 110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Metal case

• from Radiomuseum.org
• Model: Silvertone 7101AY Ch= 528.50030 - Sears, Roebuck & Co.; Chicago

• Shape
• Tablemodel, with any shape - general.

• Notes

• The SILVERTONE model 7101AY is a 17" b/w TV equipped with chassis 528.50030 and picture tube 17HP4B.Tubes and tuner : no information !



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 339 Folder 13 dated 12-56)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
