Silvertone 8009 Order=57D 8009
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1957/1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 240885
-
- Brand: Silvertone
- Number of Tubes
- 4
- Valves / Tubes
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / Either AC: 25 to 60 cycles, 110 to 120V or DC: 110 to 120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Silvertone 8009 Order=57D 8009 - Sears, Roebuck & Co.; Chicago
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 14 x 6.75 x 4.5 inch / 356 x 171 x 114 mm
- Notes
-
The Sears Silvertone 8009 is an AC/DC operated 4 tube BC band receiver. Has Qty(2) 4" PM speakers.Has phono input on rear of cabinet. Cabinet color is Brown.
The following models use the same chassis and schematic:
Model
Cabinet
8009
Brown
8010
Ivory
8011
Harmony House Ming Blue
8012
Candy Pink
- Price in first year of sale
- 25.95 $
- Mentioned in
- Machine Age to Jet Age II (page 272.)
- Literature/Schematics (3)
- Sears, Roebuck Catalogs (Silvertone) (Spring/Summer 1958, page 853.)
- Literature/Schematics (4)
- Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1957, page 1008 & page 1009.)
- Author
- Model page created by Noemi Erb. See "Data change" for further contributors.
