Silvertone 8133 Ch= 101.846 & 101.829-1
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1949 ?
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 227105
-
- Brand: Silvertone
SAMS Photofact 7/49 Folder 15 Set #66
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 33
- Valves / Tubes
- 7AG7 7F8 6AK5 7F8 6BA6 6BA6 6BA6 6AU6 6AL5 6AU6 7B5 6AU6 6AU6 6AU6 7A6 7F7 7AF7 7AF7 7B5 6AL5 6AU6 7AF7 6BG6G 5V4G 1B3GT 5U4G 5U4G 7Q7 7A7 7C6 7C5 7Z4 10BP4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Wave Bands given in the notes.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.6 inch = 24.4 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Silvertone 8133 Ch= 101.846 & 101.829-1 - Sears, Roebuck & Co.; Chicago
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
10" round CRT, US standard VHF tuner channels 2 through 13. AM tuner (540 - 1600 kc) and record player (or changer) built-in.
See also similar model Silvertone 8132 without AM/phono.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 66, Folder 15, Date 7/49)
- Literature/Schematics (1)
- Rider's TV, 2-1, 2
- Author
- Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
