• Country
• United States of America (USA)

• Manufacturer / Brand
• Sears, Roebuck & Co.; Chicago (IL)

• Year
• 1958 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 322827

• • Brand: Silvertone

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 6AF4A 2CY5 5CL8 3CB6 3CB6 5AM8 6BH8 5U8 6BN8 5AQ5 6CM7 6CG7 12AV5GA 12AX4GTA 1B3GT 21CBP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Silvertone 8161 Ch= 528.51152 - Sears, Roebuck & Co.; Chicago

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Silvertone 8161 is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis 528.51152, VHF- tuner 95-141-0, UHF tuner 95-135-0 and picture tube 21CBP4A.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 390 Folder 3 dated 3-58)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
