- Country
- Germany
- Manufacturer / Brand
- Seibt, Dr. Georg (Nachf.); Berlin, auch München
- Year
- 1929/1930
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 5828
Eigenes Bild
Eigenes Bild
Eigenes Bild
ebay_202830287363, hbredow
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- TRF with regeneration; 2 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 125/220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: EW399 - Seibt, Dr. Georg Nachf.;
- Dimensions (WHD)
- 497 x 253 x 220 mm / 19.6 x 10 x 8.7 inch
- Notes
-
Röhrentypen analog zum EW374. REN904 und RGN354 waren niemals originalbestückt!
- Net weight (2.2 lb = 1 kg)
- 8.3 kg / 18 lb 4.5 oz (18.282 lb)
- Source of data
- Radiokatalog Band 1, Ernst Erb
- Circuit diagram reference
- Röhren in FS-Bestückungstabellen
- Literature/Schematics (1)
- Arlt's grosser Radiokatalog 1930
