Scheinwiderstandsprüfer ZP3
Sennheiser Electronic (Labor W); Wennebostel
- Country
- Germany
- Manufacturer / Brand
- Sennheiser Electronic (Labor W); Wennebostel
- Year
- 1981
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 138960
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 2 x 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Scheinwiderstandsprüfer ZP3 - Sennheiser Electronic Labor W;
- Dimensions (WHD)
- 110 x 190 x 50 mm / 4.3 x 7.5 x 2 inch
- Notes
- Messfrequenzen: 63 Hz, 250 Hz, 1 kHz, 4 kHz, 8 kHz, 16 kHz;
Messbereiche:
Widerstände und Scheinwiderstände: 19,99 Ohm - 1,999 MOhm;
Kapazitäten: 5 pF - 2000 µF;
Induktivitäten: 10 µH - 5000 H;
Genauigkeit: ± 5 %;
3½-stellige LCD-Anzeige.
- Net weight (2.2 lb = 1 kg)
- 0.4 kg / 0 lb 14.1 oz (0.881 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by a member from D. See "Data change" for further contributors.
