• Country
• United States of America (USA)

• Manufacturer / Brand
• Sentinel Radio Corp., Evanston, Illinois

• Year
• 1955 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 82102

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6BE6 6BA6 6AV6 12AU7 6AQ5 6AQ5 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1U368 [Console] - Sentinel Radio Corp., Evanston

• Shape
• Console with any shape - in general

• Notes

• AC Operated AM Superheterodyne Receiver With 3 Speed automatic Record Changer.
  Console model, hi-fidelity.



• Circuit diagram reference
• Beitman Radio Diagrams Vol. 16, 1956

• Mentioned in
• Photofact Folder, Howard W. SAMS (Set 319 Folder 10 Dated 6-56)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
