- Country
- United States of America (USA)
- Manufacturer / Brand
- Sentinel Radio Corp., Evanston, Illinois
- Year
- 1933
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 57649
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 265 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Storage batteries (perhaps also batteries)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: 560 - Sentinel Radio Corp., Evanston
- Notes
- farm radio, runs on 6 V car battery or 32 V Farm system or 115 V AC/DC mains.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 3 = 1933 and before
- Other Models
-
Here you find 710 models, 350 with images and 602 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sentinel Radio Corp., Evanston, Illinois
