Ch= V75-01AA (75 Series)
Sentinel Radio Corp., Evanston, Illinois
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sentinel Radio Corp., Evanston, Illinois
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 312552
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- 6BC8 6U8 6BZ6 6BZ6 6CB6 12BY7A 6AN8 6U8 6DT6 6W6GT 6CG7 6CM7 6CG7 6DQ6 6AX4GT 1B3GT 5U4GB 21ATP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Material
- Metal case
- from Radiomuseum.org
- Model: Ch= V75-01AA - Sentinel Radio Corp., Evanston
- Shape
- Chassis only or for «building in»
- Notes
-
Sentinel Chassis model V75-01AA (75 Series) is a 21" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with VHF- tuner 700541-3 and picture tube 21ATP4A
.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 366 Folder 10 dated 8-57)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
