• Country
• People's Republic of China

• Manufacturer / Brand
• Shanghai No.2 上海无线电二厂 Shanghai No.2 Radio Factory; Shanghai

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 345428

• Number of Tubes
• 6

• Valves / Tubes
• 6A2 6K4_China 6G2 6P1_China 6E1_China 6Z4_China

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Feile Feilo 飞乐 261-7 - Shanghai No.2 上海无线电二厂

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 360 x 200 x 190 mm / 14.2 x 7.9 x 7.5 inch

• Author
• Model page created by a member from D. See "Data change" for further contributors.
