• Country
• People's Republic of China

• Manufacturer / Brand
• Shanghai No.2 上海无线电二厂 Shanghai No.2 Radio Factory; Shanghai

• Year
• 1981 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 192912

• Number of Tubes
• 6

• Valves / Tubes
• 6A2 6K4_China 6Z4_China 6N1 6P1_China unknown_Tube

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Line (AC, UC or DC not known) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 45 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Hongdeng 红灯 711-5 - Shanghai No.2 上海无线电二厂

• Notes
• One of the most advanced models in Hongdeng products with magnet antenna.

• Price in first year of sale
• 124.00 CNY

• Source of data
• Schematics for Tube Radios and Recorders, 1982, Cao Yu Heng

• Author
• Model page created by Rui Li. See "Data change" for further contributors.
